With over eight million sold, the LS2208 remains our best selling handheld laser scanner. The LS2208 has it all — enterprise class scanning in a very ergonomic and durable lightweight design that delivers all day comfort, an extra-long read range for easy scanning, plus support for everyday 1D bar codes, including high-density. With multiple interfaces, a universal cable and support for keyboards in 97 languages, the LS2208 delivers plug-and-play simplicity in virtually every corner of the world. The LS2208 — the well-proven scanner powering the checkout lines all around the world.
Capture high-density bar codes for greater application flexibility
With just one scanner, you can capture the high density bar codes common on small items.
Deploy in every corner of the world
With support for 97 international keyboards, the LS2208 is ready for operation in your country, right out of the box.
Class-leading working range
Workers can capture everyday 13 mil UPC bar codes on items that are over 25 in./63.5 cm away, improving productivity and the customer checkout experience.
More decode feedback options
Choose from a variety of options to indicate the successful capture of a bar code: the Direct Decode Indicator (a blinking laser line), a beep tone, a red/green LED indicator — or any combination of the three.
All day comfort your workers can count on
The well-proven ergonomic and lightweight balanced design provides maximum comfort, even in the most scan intensive environments. The result? Reduced user fatigue and increased worker productivity.
Durable construction
With its patented single board construction, patented frictionless liquid polymer scan element, scratch resistant tempered glass exit window and a stringent drop and tumble specification, the LS2208 delivers reliable all-day, every day operation.
Flexible handheld or hands-free operation
The optional Intellistand enables presentation scanning and allows workers to automatically switch between hands-free and handheld modes in the time it takes to drop the LS2208 into the stand.
Multiple interfaces
No matter what host you need to connect to today or tomorrow, the future proof LS2208 is ready.
Truly plug-and-play
The universal cable connects to any computing environment, practically eliminating setup and training time.
Advanced Data Formatting (ADF)
Format data properly before it is sent to your host computer, eliminating the costly modification of host software.
Product Specifications
Manufacturer
Zebra
Manufacturer Part Number
LS2208-1AZU0100ZNA
Brand Name
Zebra
Product Name
Zebra LS2208 Handheld bar code reader 1D Laser Black, White
Mfr. Part Number
LS2208-1AZU0100ZNA
Scanning
Type
Handheld bar code reader
Scanner type
1D
Sensor type
Laser
Linear (1D) barcodes supported
Codabar, Code 11, Code 128, Code 39 (ASCII), Code 93, GS1 DataBar, Pharmacode, Plessey, Standard 2 of 5
Scanner resolution
3 mm
Working distance
63.5 cm
Read rate (max)
100 reads/s
Light levels (direct sunlight)
0 - 86080 lx
Wavelength
650 nm
Tilt reading angle
-10 - 10°
Pitch reading angle
-65 - 65°
Yaw reading angle
-60 - 60°
Ports & interfaces
Connectivity technology
Wired
Standard interfaces
RS-232, RS-485, Keyboard wedge, USB
Performance
International Protection (IP) code
IP30
Protection features
Drop resistant, Scratch resistant
LED indicators
Yes
Product colour
Black, White
Certification
EN 60950-1: 2006 + A11: 2009 + A1: 2010
+ A12: 2011 + AC 2011; IEC 60950-1: 2005
+ A1: 2009; UL 60950-1, second edition;
CAN/CSA-C22.2 No. 60950-1-07
FCC 47 CFR Part 15, Subpart B, Class B; ICES-003 Issue 4, Class B; Compliant with EMC Directive 2004/108/EC
CDRH Class II; IEC Class 2
Power
Power source type
DC
Input voltage
4.5 - 5.5 V
Power consumption
175 mA
Weight & dimensions
Width
64 mm
Depth
85 mm
Height
152 mm
Weight
150 g
Packaging data
Cables included
USB
Stand included
Yes
Operational conditions
Operating temperature (T-T)
0 - 50 °C
Storage temperature (T-T)
-40 - 70 °C
Operating relative humidity (H-H)
5 - 95%
Drop resistance
0.5 m
Technical details
Compliance certificates
Federal Communications Commission (FCC), RoHS
Brand
Zebra
Availability
In Stock
Price Currency
USD
Category
Keyboards, Mice & Peripherals
